[ ARCHIVE LOG ]
Laboratory Portfolio
High-definition photos and diagnostics logs captured directly from our microscopes, multimeters, and rework stations.
Microscope Work
Micro-Soldering
Dual-Layer Board Separation under Scope
Separating sandwich motherboard layers on a modern iPhone logic board to repair internal traces.
Board Diagnostics
Samsung
Galaxy S23 FPC Socket Diagnostics
Measuring voltage drops across pins of display FPC terminals to identify broken traces.
Liquid Recovery
MacBook
MacBook Pro Liquid Corrosion Cleanup
Rebuilding corroded CD3217 controller chips and trace lines on a liquid-exposed motherboard.
Trace Surgery
Water Damage
Motherboard Trace Repair bypass
Bypassing corroded motherboard pathways using 0.02mm microscopic copper wires.
Biometric Recovery
Apple
Face ID Dot Projector Refitting
Desoldering, reballing, and calibrating original Face ID optical sensors to a new flex module.
BGA Rework
Micro-Soldering
CPU & NAND Memory Chip Transplant
Transplanting serialized memory components to a donor logic board for critical data extraction.
Repair Verification
Apple
Motherboard Swap Diagnostics Complete
System boots and passes all calibration procedures after motherboard components rebuild.
